The Model 5001N is a cashless card and ticket vending machine built around the TCD-180M dispenser, mounted in a metal cabinet with a T-handle high-security lock. It's designed for dispensing prepaid cards for laundromats, car washes, parking, transit, and similar self-service locations.
Customers pay with the Nayax Vpos Touch terminal Visa, Mastercard, Discover, American Express (magnetic stripe, chip, or RFID), Monyx Wallet, Apple Pay, or Google Wallet and the machine dispenses automatically. A low-inventory sensor lights a red LED when the card magazine is running low.
Holds roughly 160-180 standard CR80 plastic cards. Powered by a 24VDC 5-amp desktop power supply.
Model 5001N
1 / of7
Product Details
Specifications
Card Capacity
160-180+ CR80 cards at .030 in thickness
Card Dimensions
54 x 85 mm (CR80 standard)
Card Thickness Range
0.2-2.4 mm, adjustable (factory default 0.8 mm / .030 in)
Dispensing Time
Approximately 0.5 sec
Operating Voltage
24VDC (2A max, 0.1A static)
Power Supply
24VDC, 5 Amp desktop supply
Dispenser Mechanism Dimensions
9 in H x 3.25 in W x 6.5 in L
Operating Temperature
-30C to 70C (-22F to 158F)
Operating Humidity
30-90%
FCC ID
R17ME910G1WW (Nayax Vpos Touch)
Product Dimensions
9 x 7 x 18.5 in
Shipping Dimensions
20 x 10 x 10 in, 20 lbs boxed
What's in the Box
One Model 5001N card/ticket dispenser (TCD-180M mechanism) in a metal cabinet with T-handle high-security lock
